Drive Axle Forklift

Forklift Drive Axle - The piece of equipment that is elastically fastened to the frame of the vehicle utilizing a lift mast is the lift truck drive axle. The lift mast attaches to the drive axle and could be inclined, by at least one tilting cylinder, around the axial centerline of the drive axle. Frontward bearing elements combined with rear bearing components of a torque bearing system are responsible for fastening the vehicle and the drive axle frame. The drive axle can be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing parts. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is connected to the lift truck framework and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented nearly parallel to a plane extending from the axial centerline and to the swiveling axis.

Forklift units like H45, H35 and H40 which are manufactured in Aschaffenburg, Germany by Linde AG, have the lift mast tilt capably attached on the vehicle frame. The drive axle is elastically affixed to the lift truck framework by many bearing devices. The drive axle has tubular axle body along with extension arms affixed to it and extend backwards. This particular kind of drive axle is elastically attached to the vehicle frame utilizing rear bearing elements on the extension arms along with frontward bearing devices situated on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the forklift from the other bearing tool in its respective pair.

The drive and braking torques of the drive axle on this unit of forklift are sustained using the extension arms through the back bearing parts on the frame. The forces created by the lift mast and the load being carried are transmitted into the floor or road by the vehicle framework through the front bearing elements of the drive axle. It is important to make sure the parts of the drive axle are put together in a firm enough manner to maintain strength of the lift truck truck. The bearing elements could lessen small bumps or road surface irregularities through travel to a limited extent and offer a bit smoother function.
